Utility locating is the process of identifying and marking underground utilities like gas lines, water pipes, and electrical cables before excavation begins. For manufacturing plants, this is critical to avoid accidents, costly damages, and production delays. With over 20 million miles of underground utilities in the U.S., the risks of striking these lines are high, leading to safety hazards and financial losses.

Here are the key points:

• Why It Matters: Striking utilities can cost $56,000 per incident and cause months of downtime.
• Legal Requirements: Federal and state laws mandate contacting 811 and using professional locating services.
• Methods Used:
  • Electromagnetic Locating: Detects metallic utilities.
  • Ground-Penetrating Radar (GPR): Finds both metallic and non-metallic lines.
  • Hydro-Excavation: Safely exposes utilities using pressurized water and vacuum systems.
• Public vs Private Services:
  • Public services (via 811) are free but limited to utilities up to the property line.
  • Private services cover internal utilities and offer higher accuracy but cost $100–$1,500.

Professional utility locating ensures safety, reduces costs, and keeps projects on schedule. Manufacturing plants benefit from precise mapping, compliance with regulations, and avoiding downtime caused by utility strikes.

Locating underground utilities - Avoiding Utilities Strikes series

Utility Locating Methods for Manufacturing Facilities

Manufacturing facilities rely on several techniques to detect underground utilities before starting excavation work. Each method caters to specific needs, helping facility managers choose the best option for their infrastructure challenges.

Electromagnetic Utility Locating

Electromagnetic (EM) locating is a widely used method for detecting metallic utilities, such as pipes and cables, underground. This technique works by either transmitting signals into buried metallic objects or detecting signals from live cables. For non-metallic pipes, tools like rodder/sonde combinations can be used to extend detection capabilities.

While EM locating is a cost-effective solution for conductive materials, it does have limitations. Plastic pipes, fiber optic cables, and other non-metallic utilities cannot be detected with this method. Despite this drawback, EM locating remains a practical choice for identifying metallic infrastructure.

Ground-Penetrating Radar (GPR)

Ground-Penetrating Radar (GPR) offers a more versatile approach by detecting both metallic and non-metallic utilities. It works by sending radio frequency pulses into the ground and analyzing their reflections to create a visual representation of subsurface features. This makes GPR effective for locating pipes, cables, conduits, and even structural elements like reinforcement bars or post-tension cables in concrete.

However, GPR's performance can be influenced by soil type and the depth of the utilities. It also requires a higher upfront investment and operational costs. Despite these challenges, the accuracy and detailed mapping it provides make it invaluable for complex utility detection. For instance, in 2024, GPRS collaborated with the University of Toledo to deliver high-accuracy GPR services while offering field training for their Project Managers.

Hydro-Excavation

Hydro-excavation is a non-destructive method used to expose utilities once their locations have been identified by EM or GPR. This technique uses pressurized water to break up soil and a vacuum system to remove the resulting debris. The process creates precise openings, allowing operators to reveal underground utilities without causing damage.

For manufacturing facilities, hydro-excavation offers unmatched precision and safety. It reduces production downtime and prevents costly repairs by minimizing the risk of damaging critical infrastructure. This method is particularly useful for tasks like installing new equipment foundations, upgrading utility connections, or performing maintenance near existing systems. According to the Common Ground Alliance, around 1,100 utility strikes occur daily, making hydro-excavation's safety benefits essential for maintaining operational reliability.

Skilled operators are crucial for hydro-excavation, as the process involves handling pressurized water and vacuum systems near live utilities. Proper training ensures the equipment is used safely and effectively, reducing the likelihood of accidental damage.

A Comprehensive Approach

Manufacturing facilities often achieve the best results by combining these methods into a comprehensive utility locating strategy. Hiring a professional utility locating company and contacting 811 are essential steps to accurately map buried infrastructure. This multi-method approach enhances both accuracy and safety, which is critical given the high number of utility incidents reported nationwide.

Public vs Private Utility Locating Services

Manufacturing plants rely on both public and private utility locating services to map underground utilities and reduce risks during excavation or construction projects.

Public Utility Locating Services Explained

Public utility locating services are accessed through the 811 "Call Before You Dig" hotline, a free service that identifies utilities owned and maintained by municipalities or utility companies. These services mark utilities up to the property line or service meter, covering infrastructure like water mains, gas lines, buried electric lines, fiber optic cables, telecommunications lines, mainline sewers, and stormwater systems.

While the 811 system follows standardized procedures, it has limitations. For instance, it does not provide information on utility depths, and the markings have a 25-inch tolerance from the actual utility location. Additionally, response times typically range from 3 to 5 days, which may not meet the tight deadlines of manufacturing projects. Another challenge is the difficulty in locating non-metallic utilities, such as plastic pipes or fiber optic cables, which are often undetectable by public services.

When Manufacturing Plants Need Private Utility Locating

Manufacturing facilities often require private utility locating services to address gaps left by public locators. With approximately 65% of underground utility lines in the U.S. being privately owned, public services alone cannot provide the comprehensive coverage needed.

Private utility locating services specialize in identifying utilities that fall outside the scope of public services, such as internal gas lines, process lines, and electrical feeders specific to manufacturing operations. These services use advanced tools and techniques to map even the most complex utility networks with precision. For example, private locators employ ground-penetrating radar and electromagnetic detectors to locate utilities, measure depths, and even identify abandoned lines.

Private locating services boast a success rate of over 99% in identifying utilities without causing damage, compared to public services, which typically account for only about 40% of utilities in a given area. This accuracy translates into significant savings - each correctly located utility line can prevent damage costs averaging $56,000.

Feature	Public Utility Locating	Private Utility Locating
Cost	Free	$100–$1,500
Coverage Area	Up to property line	Beyond the service meter
Response Time	3–5 days	Often same-day service
Utility Types	Public infrastructure	Private utilities and networks
Accuracy	25-inch tolerance	99%+ success rate

Private utility locating is especially important for manufacturing plants, where utility strikes can lead to 2–3 months of project downtime. By combining public and private locating services, facilities can ensure comprehensive coverage. A good strategy is to start with 811 to mark public utilities, then bring in private locators to address the remaining underground infrastructure. This approach not only minimizes risks but also tackles issues like the 25% of damages in 2022 caused by failing to notify 811 and the 163,726 reported utility strikes that same year. Together, these services enhance safety and keep projects running smoothly.

sbb-itb-5cd57bf

Benefits of Professional Utility Locating for Manufacturing Plants

Hiring professional utility locating services offers far-reaching advantages that go beyond meeting compliance standards. For manufacturing facilities, these services translate into improved safety measures, reduced costs, and more efficient operations.

Safety and Risk Reduction

One of the most critical benefits of professional utility locating is the significant reduction in risks to both people and property. Hitting a gas pipeline can cause fires or release toxic gases, while striking electrical lines could result in severe injuries or fatalities. These incidents are more than just operational hiccups - they can endanger lives and disrupt entire facilities.

Over the last two decades, utility strikes have caused $1.7 billion in property damage, 1,906 injuries, and 421 deaths. Manufacturing plants are especially vulnerable due to the intricate underground networks that support their operations.

By using advanced techniques, professional locating services help prevent accidental damage to critical infrastructure, including gas lines, water pipes, electrical cables, and communication systems.

"Utility locating is crucial to prevent disruptions, avoid financial losses, and ensure crew safety." - Mason Private Locating LLC

This proactive approach not only enhances safety but also helps facilities save money in the long run.

Cost Savings and Project Timeline Management

Investing in professional utility locating services pays off in more ways than one. Facilities can avoid costly damages and streamline project timelines, ultimately boosting overall efficiency.

Delays caused by utility strikes can be devastating. A survey revealed that 68% of facility managers experienced project downtimes of 2-3 months due to underground utility damage. Such delays lead to lost productivity, missed deadlines, and ripple effects throughout the supply chain.

The financial benefits of professional locating services are well-documented. For instance, a Pennsylvania Department of Transportation study showed that every $1.00 spent on Subsurface Utility Engineering (SUE) saved $11.39. Similarly, a Louisiana study reported savings of $2.73 for every $1.00 spent on SUE.

A real-world example comes from a mid-sized fiber company that adopted digital locating technology. This move reduced their locating costs by 68%, improved on-time locates from 44% to over 80%, and cut damages by 20%.

Rework is another costly issue that professional locating services can help avoid. The median cost of rework on construction projects typically falls between 4-6% of the total project cost. By identifying potential conflicts before digging begins, these services help manufacturing plants sidestep expensive setbacks.

Better Data Accuracy and Mapping

Beyond cost and safety benefits, professional utility locating ensures precise mapping and data accuracy, which are critical for managing infrastructure over the long term. Reliable utility data is essential for maintaining infrastructure and adhering to regulations. Manufacturing facilities gain access to detailed maps and documentation, creating a valuable resource for future projects and routine maintenance.

Poor data quality is a leading cause of utility strikes. In 2022 alone, over 3,550 utility strikes were attributed to inaccurate maps, and 34,000 strikes occurred due to locator errors. Professional services provide accurate, up-to-date mapping to help facilities avoid becoming part of these statistics.

Detailed documentation also supports regulatory compliance and safety audits. Manufacturing plants can demonstrate thorough planning and maintain clear records of their underground systems, which proves invaluable during expansions, equipment installations, or maintenance tasks.

"By preventing costly utility damage and delays, we can help you save time and money while ensuring the safety of your team and the surrounding community." - NG Companies

Professional utility locating turns hidden risks into clear, actionable data, enabling safer and more efficient project planning for manufacturing facilities.

Legacy HydroX Utility Locating Services for Manufacturing Plants

Legacy HydroX has spent over 15 years serving manufacturing facilities across the United States, specializing in utility locating and hydro-excavation. Founded by two brothers with extensive industry knowledge, the company has earned a reputation for delivering precise, safe, and reliable non-destructive services. Their work not only protects critical infrastructure but also ensures that operations remain efficient and uninterrupted.

By refining established industry practices, Legacy HydroX has tailored its methods to meet the unique challenges of manufacturing environments. Let’s explore how their modern techniques help safeguard these operations.

Non-Destructive Hydro-Excavation Services

At the heart of Legacy HydroX’s utility locating services is their advanced hydrovac technology. This system uses high-pressure water and a vacuum to carefully expose underground utilities. By avoiding traditional digging methods, this approach reduces risks and ensures greater precision, making projects safer and more successful.

Their services include potholing and utility locating, both of which comply with state excavation laws. These efforts provide manufacturing facilities with critical subsurface details, such as utility locations, depths, and conditions. This information is essential for expansions, equipment installations, and ongoing maintenance.

"At Legacy Hydro Vac, our mission is to provide safe, precise, and dependable non-destructive hydro-excavation and industrial cleaning services that protect infrastructure, safeguard people, and support the communities we serve."

Additional Industrial Support Services

Legacy HydroX goes beyond utility locating to offer a wide range of industrial services designed to support manufacturing operations. Their caisson excavation services ensure stable, precise foundations for structural and geotechnical projects. They also provide hydro jetting, which uses high-pressure water to clear grease, roots, debris, and mineral buildup from drainage systems and industrial piping.

For facilities relying on rail transport, Legacy HydroX offers mobile railcar cleaning, ensuring that these critical assets remain operational. Additionally, their industrial cleaning services extend to production equipment, storage tanks, and infrastructure, helping facilities maintain peak performance.

These additional services enhance the reliability and efficiency of manufacturing operations, giving facilities the tools they need to succeed.

Why Choose Legacy HydroX

Manufacturing plants choose Legacy HydroX for several compelling reasons that directly contribute to their operational success. The company’s 24/7 availability ensures urgent utility locating needs are addressed promptly, minimizing downtime and keeping projects on track.

With over 15 years of experience, Legacy HydroX understands the specific challenges faced by manufacturing environments. Their founders’ deep expertise translates into practical, effective solutions for the real-world problems industrial facilities encounter.

Legacy HydroX’s non-destructive methods protect critical infrastructure, helping facilities avoid the expensive damages often caused by traditional excavation techniques. Additionally, their commitment to compliance with state excavation laws gives manufacturers peace of mind, ensuring projects meet regulatory standards and supporting the continuity of operating permits and certifications.

Key Points for Manufacturing Plants

Manufacturing plants face serious risks, including costly accidents, without proper utility locating. With over 20 million miles of underground utility lines crisscrossing the United States, the stakes are high for ensuring safety and operational efficiency. It's essential for managers to understand these risks and take proactive steps to protect their facilities.

A single utility strike can result in an average repair cost of $56,000 and cause significant downtime, often lasting 6–8 weeks. Take, for instance, the 2019 incident in San Francisco, where an excavation crew damaged a gas line due to insufficient utility locating efforts. Such scenarios highlight the importance of thorough preparation.

Addressing both public and private utility networks is another critical aspect. Manufacturing facilities often rely on private utility locating services, as private lines make up over 60% of all utility lines in the United States. Ignoring these private lines can lead to unexpected disruptions and safety hazards.

One of the leading causes of utility strikes - accounting for 94% of cases - is inaccurate or incomplete utility data. Advanced methods, such as electromagnetic detection, ground-penetrating radar, and hydro-excavation, can achieve an impressive 99.8% accuracy rate in utility mapping. These techniques provide a detailed and reliable understanding of underground infrastructure.

Staying compliant with state laws is another key benefit of professional utility locating services. These services ensure that excavation projects meet legal requirements and help facilities secure the necessary permits and certifications, which are especially critical during expansions or when installing new equipment.

While private utility locating services typically cost between $100 and $1,500, depending on the project's scope, this expense is a worthwhile investment. It prevents the far greater costs associated with utility strikes, project delays, and extended downtime. Accurate utility locating not only safeguards critical infrastructure but also keeps operations running smoothly and within budget.

FAQs

What risks do manufacturing plants face if underground utilities aren’t located before excavation?

Failing to identify underground utilities before starting excavation can lead to a host of problems. Hitting a utility line isn’t just a minor mishap - it can create serious safety risks like gas leaks or electrical shocks, endangering workers on-site. Beyond safety, it can also cause property damage, lead to expensive repairs, and throw your project timeline completely off track.

The trouble doesn’t stop there. Striking utility lines can bring legal consequences, including hefty fines and penalties. On top of that, you’ll likely face increased costs for emergency repairs and unplanned downtime. Taking the time to locate utilities properly isn’t just a precaution - it’s a necessity to protect workers, prevent disruptions, and ensure your project stays on schedule and within budget.

What’s the difference between private utility locating services and the 811 hotline, and why should manufacturing plants consider private services?

Private utility locating services specialize in pinpointing underground utilities on private properties, whereas the 811 hotline focuses on marking utilities in public areas or rights of way. While the 811 service is crucial for maintaining safety during excavation, it typically doesn't address utilities located solely on private land.

Manufacturing plants often turn to private utility locating services for a more comprehensive and precise evaluation of underground utilities, including those not covered by public services. This extra level of accuracy helps avoid expensive damages, protects workers, and reduces operational disruptions.

What makes Ground-Penetrating Radar (GPR) a better choice for locating utilities in manufacturing facilities?

Ground-Penetrating Radar (GPR) is a non-invasive and efficient way to locate underground utilities in manufacturing facilities. What sets GPR apart is its ability to detect both metallic and non-metallic objects, offering a thorough view of what's beneath the surface.

Because GPR doesn't require any digging, it’s a safer and quicker option, especially in environments where disruptions can be costly. Its accuracy and adaptability make it a reliable tool for ensuring safety and minimizing interruptions in manufacturing operations.
